YEAPHI 800W 1000W 36V 48V 3000rpm brushless DC blade motor controller for walking mower

    • YEAPHI 800W 1000W 36V 48V 3000rpm ElectroCraft Brushless DC Motors bldc motor is a production motor over 4 years. It’s a mature products with perfect technology and passed the market verification.

We provide you with

  • Free customized development.

  • Professional service-YEAPHI

    has 3 research and development centers that solve customers' technical challenges.

  • Excellent cost control

    based on high self-manufactured ratio.

  • Full compliance

    with IATF16949 standards.

  • Over 5 years' experience

    in electric lawn vehicle based on cooperating with RYOBI and Greenworks.

  • Products catalogue

    ● 800W-5KW blade controller.
    ● 800W-5KW blade motor.
    ● 800W-5KW driving controller.
    ● 800W-5KW driving motor.
    ● 1KW-1.2KW driving train including driving motor, gearbox and brake.
    ● Angle sensor.

Product features

  • 01

    Main characteristics

      • System power-on self-check function.
      • Energy feedback braking.
      • Brake, cruise, three gear speed selection interface.
      • IP65 Integral waterproof terminal interface.
      • PWM output port.
      • LED working state, failure state indication.
      • Ultra-thin shape design, easy to install on the whole vehicle.
  • 02

    Electric parameters

      • Rated voltage: 40V.
      • Current:: 25A.
      • Output voltage:14.5±0.5V(DC); 5.0±0.2V(DC); 3.3±0.1V.
      • Under-voltage value: <39±1V.
      • Over-voltage value: >58±2V.
      • Overheating protection: 85±3℃.
  • 03

    Comfortable operation experience

      • Direct torque control, smooth start, good acceleration performance, especially in the middle and high speed segment, similar to the handling performance of fuel motorcycle.
  • 04

    Ultra-low noise

      • Vector controlled sinusoidal current output, motor output torque smooth, fully inhibit the motor torque fluctuation caused by low frequency noise.
  • 05

    Perfect protection function

      • Signal integrity judgment (motor interface signal, control signal, etc.).
      • Over current, over and under voltage, over temperature protection.
      • Provide motor temperature control interface.
  • 06


      • Electric walking mower.


Power Voltage Current Rated speed IP Level Working method Temperature protection
800W/1000KW 36V-40V 25A 3000rpm IP65 S1 85℃

Product Advantages

1.The motor is unidirectional rotation.
2.Insulation level:H.
3.leak current: Applied AC voltage between windingand iron core 1.8±0.1KV/3S, leak current ≤3mA.
  • pro_service

    Main characteristics

    ►System power-on self-check function.
    ►Energy feedback braking.
    ►Brake, cruise, three gear speed selection interface.
    ►IP65 Integral waterproof terminal interface.
    ►PWM output port.
    ►LED working state, failure state indication.
    ►Ultra-thin shape design, easy to install on the whole vehicle

  • pro_service

    Electric parameters

    ►Rated voltage: 40V.
    ►Current: 25A.
    ►output voltage: 14.5±0.5V(DC); 5.0±0.2V(DC); 3.3±0.1V.
    ►Under-voltage value: <39±1V.
    ►Over-voltage value: >58±2V.
    ►Overheating protection: 85±3℃.
