YEAPHI 1.2KW 48V 72V 3600rpm 3800rpm brushless DC blade motor for electric Zero Turn Lawn Mower tractor

    • The 1.2KW 48v 72V 3600rpm 3800rpm brushless DC blade motor is used for the ride on tractor and electric zero turn lawn mower. The motor rotates bidirectional with H insulation level. The torque is 3.1N.m and has an IP65 level waterproofing grade.
  • Large
  • application-1
  • application-2
  • application-(4)
  • application-(5)
mailCONTACT NOW pdfpdf Download

We provide you with

  • Free customized development.

  • Professional service-YEAPHI

    has 3 research and development centers that solve customers' technical challenges.

  • Excellent cost control

    based on high self-manufactured ratio.

  • Full compliance

    with IATF16949 standards.

  • Over 5 years' experience

    in electric lawn vehicle based on cooperating with RYOBI and Greenworks.

  • Products catalogue

    ● 800W-5KW blade controller
    ● 800W-5KW blade motor
    ● 800W-5KW driving controller
    ● 800W-5KW driving motor
    ● Angle sensor

Product features

  • 01

    Application

      • Electric lawn tractor.
      • Electric lawn tractor.
  • 02

    Specifications

      • 1.Power: 1KW/1.2KW.
      • 2.Voltage: 48V/72V.
      • 3.Gearbox ratio: 28:1.
      • 4.Torque: 2.52N.m.
      • 5.Max torque: 220N.m.
      • 6.Rated speed: 3600rpm-4600rpm.
      • 7.Working method: S2.
      • 8.IP level: IP65.
      • 9.Insulation level: H.
      • 10.Rotation:The motor rotates bidirectional.
      • 11.leak current: Applied AC voltage between windingand iron core 1.8±0.1KV/3S,leak current ≤3mA.
  • 03

    Products advantage

      • Small size, light weight, high output power.
      • High efficiency, high relative density of output power and torque.
      • The speed adjustment range is wide, and it can be operated in most working places.
      • Simple structure, reliable operation and convenient maintenance.
      • It has the characteristics of good low-voltage characteristics, strong torque load characteristics, large starting torque, and small starting current.
  • 04

    Certification

      • ISO9001
      • ISO14001
      • ISO45001
  • 05

    QC Tools

      • APQP
      • FMEA
      • PPAP
      • MSA
      • SPC
  • 06

    Process Inspection Technology

      • Automatic Electric Strength Test.
      • Automatic Aging Test.
      • Automatic Final Test.
      • Digital Quality Tracing.

Specifications

Power Voltage Torque Max torque Rated speed
1.2KW 48V/72V 3.1N.m 9.3N.m 3800rpm

Product Advantages

1. The motor rotates bidirectional.
2. Insulation level:H.
3. leak current: Applied AC voltage between windingand iron core 1.8±0.1KV/3S, leak current ≤3mA.
  • pro_service

    Specifications

    ►Power: 1.2KW.
    ►Voltage: 48V/72V.
    ►Torque: 3.1N.m.
    ►Max torque: 9.3N.m.
    ►Rated speed: 3800rpm.
    ►Working method: S2.
    ►IP level: IP65.
    ►Insulation level: H.
    ►Rotation: The motor rotates bidirectional.
    ►Leak current: Applied AC voltage between windingand iron core 1.8±0.1KV/3S, leak current ≤3mA.

  • pro_service

    Products Advantage

    ►Small size, light weight, high output power.
    ►High efficiency, high relative density of output power and torque.
    ►The speed adjustment range is wide, and it can be operated in most working places.
    ►Simple structure, reliable operation and convenient maintenance.
    ►It has the characteristics of good low-voltage characteristics, strong torque load characteristics, large starting torque, and small starting current.
