YEAPHI 1.2KW 48V 72V 3600rpm 3800rpm brushless DC blade motor for electric Zero Turn Lawn Mower tractor

    • The 1.8 kw 48v/72v blade motor is used for the ride on tractor Lawn Vehicle. It is used for lawn mower. We have 800W to 5.5KW motors and controllers used for battery-powered equipment.The applications of our products are Electric push lawn mower, Electric zero turn mower, and riding tractor, etc.
    • There are about 27 years experiences in this industry. We are the specified supplier who cooperates with many famous customers in this industry for a long time, such as Greenworks，Ryobi, TTI, Alamo Group, Briggs&Stratton and Generac.
  • Large
  • application-1
  • application-2
  • application-(5)
  • application-(4)
mailCONTACT NOW pdfpdf Download

We provide you with

  • Free customized development.

  • Professional service-YEAPHI

    has 3 research and development centers that solve customers' technical challenges.

  • Excellent cost control

    based on high self-manufactured ratio.

  • Full compliance

    with IATF16949 standards.

  • Over 5 years' experience

    in electric lawn vehicle based on cooperating with RYOBI and Greenworks.

  • Products catalogue

    ● 800W-5.5KW blade controller.
    ● 800W-5.5KW blade motor.
    ● 800W-5.5KW driving controller.
    ● 800W-5.5KW driving motor.
    ● Angle sensor.

Product features

  • 01

    Application

      • ZTR Lawn mower, Lawn tractor.
  • 02

    Features

      • 1. Compact design, water resistant, stainless steel shaft.
      • 2. Low noise, high torque, high reliability.
      • 3. Stepless speed control, dual-direction.
      • 4. Long working life (>20,000 hours).
  • 03

    Eletronic Parameters

      • 1. Rated voltage: 48/72(DC).
      • 2. Output power: 1.8kw.
      • 3. Motor torque:4.8 N.m.
      • 4. Rated speed: 3600±100.
      • 5. IP level: IP 65.
      • 6. Counter electromotive force(v/1000rpm)14v ±5%.
      • 7. Dynamic inductance min（uH): 165±6%.
      • 8. Static inductance Max(uH):283±6%.
      • 9. Resistane(Ω)/25℃3:0.0281±5%.
  • 04

    Products advantage

      • Small size, light weight, high output power.
      • High efficiency, high relative density of output power and torque.
      • The speed adjustment range is wide, and it can be operated in most working places.
      • Simple structure, reliable operation and convenient maintenance.
      • It has the characteristics of good low-voltage characteristics, strong torque load characteristics, large starting torque, and small starting current.
  • 05

    Certification

      • ISO9001
      • ISO14001
      • ISO45001
  • 06

    QC Tools

      • APQP
      • FMEA
      • PPAP
      • MSA
      • SPC
  • 07

    Process Inspection Technology

      • Automatic Electric Strength Test.
      • Automatic Aging Test.
      • Automatic Final Test.
      • Digital Quality Tracing.
  • 08

    Company Advantages

      • Over 5 years’ experience in electric lawn vehicle based on cooperating with RYOBI and Greenworks.
      • Free customized development.
      • Excellent cost control based on high self-manufactured ratio.
      • We are in full compliance with IATF16949 standards.

Specifications

Power Voltage Torque Rated speed Working method IP level Counter electromotive force(v/1000rpm) Dynamic inductance min(uH) Static inductance Max(uH) Resistane(Ω)/25℃3
1.8KW 48/72V 4.8 N.m 3600±rpm S1  IP 65 v/rpm14v ±5% 165±6% 283±6 0.0281±5%

Product Advantages

1. After the product assembly, the motor shaft should be flexible rotation, without lag, no sound.
2. The motor is unidirectional rotation: the shaft extension end is regarded as counterclockwise rotation.
3. Motor slot pole ratio: stator 12 slot, rotor 10 pole (5 opposite pole).
4. Insulation grade: grade H (injection molding material: grade F).
5. Magnetic steel temperature resistance grade: SH grade.
6. Leakage current: AC voltage 1.8±0.1K/3S between the winding and the core, leakage current 3 mA.
  • pro_service

    Specifications

    1. Rated voltage: 48/72(DC).
    2. Output power: 1.8kw.
    3. Motor torque:4.8 N.m.
    4. Rated speed: 3600±100.
    5. IP level: IP 65.
    6. Counter electromotive force(v/1000rpm)14v ±5%.
    7. Dynamic inductance min（uH): 165±6%.
    8. Static inductance Max(uH):283±6%.
    9. Resistane(Ω)/25℃3: 0.0281±5%.

  • pro_service

    Products Advantage

    ►Small size, light weight, high output power.
    ►High efficiency, high relative density of output power and torque.
    ►The speed adjustment range is wide, and it can be operated in most working places.
    ►Simple structure, reliable operation and convenient maintenance.
    ►It has the characteristics of good low-voltage characteristics, strong torque load characteristics, large starting torque, and small starting current.
